Multi Function CNC 5 Axis Bridge Saw TITAN PLUS 5+

Name:Multi Function CNC 5 Axis Bridge Saw TITAN PLUS 5+

Details

TITAN PLUS 5+ is the new generation multi-function processing machine which is associated to be designed and manufactured between OMC and research institute of famous college. With pattern operation and advanced control system and synchronous CNC control system, the machine can be easily operated easily without knowing complicated CNC knowledge. This machine can be used to realize some advanced functions like : cutting line, chamfering, drilling, profiling, 3D profiling, and edge profiling, which can be used to small processing factory and countertop shops.

Characteristic

1.Compact size without needing the ground base

2. Powerful 11kw motor with adjustable speed.

3.With less electricity and more efficiency, the cost is decreased much.

4.High quality accessories and electric parts are used to secure long service life and low cost.

Technical Parameters and Price

Model TITAN PLUS 5+
Programming method 1 CAD& Manual
Control method CNC
Main motor power 11kw 380V
R.P.M 1000-6000r/min
Blade size 400mm
X-axis working stroke 3200mm
Y-axis working stroke 2000mm
Z-axis working stroke 290mm
A-axis working stroke 360°free rotation
B-axis working stroke Auto 0-90 degree chamfer
Cutting thickness 100mm
Working table size 3200*2000mm
Overall size 5800*3120*3320mm
Weight 4200KG
